HLC-2PKQ 1

HLC-2PKQ

5 Megapixel Parking Detection IP Camera


  • 5 Megapixel Parking Detection IP Camera
  • Built-in LPR and Parking Space Occupancy Detection
  • LPR and Parking Space Occupancy Detection Accuracy Rate >99%
  • Lens designed to monitor both sides of the parking lot and can detect up to 6 parking spaces simultaneously
  • Supports Parking Space Status,  Parking time Counting,  Line-Crossing Detection, Space-Crossing Detection,  Special Vehicle Parking Space Detection (Electric Vehicle,  Disabled Parking Permit), etc.
  • Adjustable 6 Indicator Colors for Displaying Different Status of the Assigned Parking Space
  • H.264+ / H.264 / M-JPEG Video Compression
  • True Wide Dynamic Range
  • 3D Noise Reduce
  • Watermark
  • Two way Audio
  • Region of Interest
  • Two RJ45 Plugs Support PoE Connection up to 6 Cameras
  • SDK for Software Integration
Product Name 5MP Parking Detection IP Camera
Model HLC-2PKQ
Max. Resolution 2560x1920 (5MP)
Sensor 1/2.7" CMOS Sensor
Lens 3.6mm@F2.2,    2.8mm@F2.2
FOV 3.6mm   Horizontal: 76°,   Vertical: 55°
2.8mm   Horizontal: 91°,   Vertical: 66°
Lens Adjustment Range Horizontal: -30° ~ 30°,   Vertical: 0° ~ 35°
Sensitivity Color: 0.08 Lux (AGC ON),   B/W: 0.05 Lux (AGC ON)
Video Format H.264+ / H.264 / MJPEG
Video Resolution 2560x1920,  2592x1520,  1920x1080,   1280x720,  640x480@30fps
FPS Dual Lens: 15fps,    Single Lens: 30fps
Max. Streams Quadruple Streaming
Audio Format G.711 (64K) and G.726 (32K, 24K) audio compression,
Input: Microphone Speaker built-in
Interface DOx2,  RS485
Network Protocol IPv6,  IPv4,  HTTP,  HTTPS,  SNMP,  SSL,  TLS,  DNS,  ICMP,  IGMP, ARP,  SNTP,  QoS/DSCP,  RTMP,  IEEE 802.1X,  RTSP/RTP/RTCP,  TCP/IP,  UDP,  SMTP,  FTP,  PPPoE,  DHCP,  DDNS,  NTP,  UPnP,  Samba,  Bonjour, ONVIF Profile S,  ONVIF Profile T,  ONVIF Profile G
Power Consumption DC 12V Max.: 10.8W,   PoE Max.: 12.2W
Features Region of Interest,  Advanced Smart Stream,  Motion Detection,  Privacy Mask,  Defog,  Tampering Detection,  Corridor Mode,  Push Video,   P2P (Optional)
AI Features Built-in AI deep-learning algorithm,   Supporting ANPR and parking space detection
Parking Space Occupancy Detection Dual Lens: Simultaneously monitoring 2x2 : 2x3  Parking spaces,
Single Lens: Simultaneously monitoring 1x2 : 1x3 Parking spaces
LED Indicator For Space  Occupancy Status 6 Customizable colors for different occupancy status
Green / Blue / Red / Pink / Cyan / Yellow
Dimensions Flat-faced: W146 x H95.7 x D133.9 (mm)
Circular: W146 x H130.9 x D133.9 (mm)
Weight Dual Lens: 650 (g),  Single Lens: 630 (g)
Working Temp. -20°C ~ 50°C  /  -4°F ~ 122°F
◊ Specification are subject to change without notice please contact us for any further inquiry of customization demands
Document Type Date Version Size Download
Manual   20240618   6.3 Mb
Datesheet   20240618   1.6 Mb
IP Scanner   20240618   1.7 Mb
