Name: HLV-1WKQ
Brand: HUNT ELECTRONIC CO., LTD.
SKU: 5MP H.264 Vandal Dome IP Camera

HLV-1WKQ

5MP H.264+ Vandal Dome IP Camera

5 Megapixel IR Vandal Dome IP Camera
H.264⁺ / H.264 / M-JPEG Compression
Region of Interest (ROI) Function
Advanced Smart Stream
Digital Noise Reduction
Power over Ethernet (PoE)
True Wide Dynamic Range 100 (dB)
Day & Night Manual Switch Time Control
IR LED Built-in 40 (M)
IR Cut Filter Mechanism
Micro SD Card Backup (Optional)
2-way Audio
IP66, IP68, IK10
Support iPhone / Mac / Android
SDK for Software Integration
Free Bundle 36Ch Recording Software

Product Name	H.264⁺ 5MP Varifocal IR Vandal Dome
Model	HLV-1WKQ
Max. Resolution	2592x1944 (5MP)
Sensor	1/2.7" CMOS Sensor
Lens	2.8-12mm Varifocal Lens @ F1.4
Sensitivity	Color: 0.008 Lux (AGC ON), B/W: 0.003 Lux (AGC ON)
FOV	Horizontal: 32.6° ~ 93.8°, Vertical: 23.9° ~ 67.9°
IR Distance	4 x High Power LEDs, 850nm, IR Distance 40 (M)
Video Format	H.264⁺ / H.264 / MJPEG
Video Resolution	2594x1944@30fps, 2594x1520@30fps, 1920x1080@30fps, 1280x720@30fps, 640x480@30fps
Max. Streams	4 Streams
Audio Format	G.711 (64K) / G.726 (32K, 24K)
Audio	Input: External Audio in, Output: External Line out, Support 2 way Audio
Interface	DIx1, DOx1, Micro SD Card Slot (Optional), RJ45, DC Jack
Network Protocol	IPv6, IPv4, HTTP, HTTPS, SNMP, SSL, TLS, DNS, ICMP, IGMP, ARP, SNTP, QoS/DSCP, IEEE 802.1X, RTSP/RTP/RTCP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, Samba, Bonjour, ONVIF Profile S, ONVIF Profile T, ONVIF Profile G
Power Consumption	DC 12V Max.: 4.9W, PoE Max.: 5.8W
Special Features	Region of Interest, Advanced Smart Stream, Motion Detection, Privacy Mask, Defog, Lens Distortion Correction, Corridor Mode, Tampering Detection, Noise Reduction, Push Video, P2P (Optional)
AI Features (Optional)	Crowd Detection, Queue Detection, Intrusion Detection, Loitering Detection, Line Crossing Detection, Enter/ Exit Counting, Parking Detection
Dimensions	Ø137 x H102 (mm)
Weight	890 (g)
Working Temp.	-20°C ~ 60°C / -4°F ~ 140°F
◊ Specification are subject to change without notice please contact us for any further inquiry of customization demands

Document	Type	Date	Version	Size	Download
Manual		20250723		5.2 Mb
Datesheet		20220822		1.6 Mb
IP Scanner		20180726		1.7 Mb

HLV-1WKQ Accessories
Pole Mount Adapter	L-shap Bracket	Ø3.5mm Stereo Jack Microphone

Features

5 Megapixel IR Vandal Dome IP Camera
H.264⁺ / H.264 / M-JPEG Compression
Region of Interest (ROI) Function
Advanced Smart Stream
Digital Noise Reduction
Power over Ethernet (PoE)
True Wide Dynamic Range 100 (dB)
Day & Night Manual Switch Time Control
IR LED Built-in 40 (M)
IR Cut Filter Mechanism
Micro SD Card Backup (Optional)
2-way Audio
IP66, IP68, IK10
Support iPhone / Mac / Android
SDK for Software Integration
Free Bundle 36Ch Recording Software

Specification

Product Name	H.264⁺ 5MP Varifocal IR Vandal Dome
Model	HLV-1WKQ
Max. Resolution	2592x1944 (5MP)
Sensor	1/2.7" CMOS Sensor
Lens	2.8-12mm Varifocal Lens @ F1.4
Sensitivity	Color: 0.008 Lux (AGC ON), B/W: 0.003 Lux (AGC ON)
FOV	Horizontal: 32.6° ~ 93.8°, Vertical: 23.9° ~ 67.9°
IR Distance	4 x High Power LEDs, 850nm, IR Distance 40 (M)
Video Format	H.264⁺ / H.264 / MJPEG
Video Resolution	2594x1944@30fps, 2594x1520@30fps, 1920x1080@30fps, 1280x720@30fps, 640x480@30fps
Max. Streams	4 Streams
Audio Format	G.711 (64K) / G.726 (32K, 24K)
Audio	Input: External Audio in, Output: External Line out, Support 2 way Audio
Interface	DIx1, DOx1, Micro SD Card Slot (Optional), RJ45, DC Jack
Network Protocol	IPv6, IPv4, HTTP, HTTPS, SNMP, SSL, TLS, DNS, ICMP, IGMP, ARP, SNTP, QoS/DSCP, IEEE 802.1X, RTSP/RTP/RTCP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, Samba, Bonjour, ONVIF Profile S, ONVIF Profile T, ONVIF Profile G
Power Consumption	DC 12V Max.: 4.9W, PoE Max.: 5.8W
Special Features	Region of Interest, Advanced Smart Stream, Motion Detection, Privacy Mask, Defog, Lens Distortion Correction, Corridor Mode, Tampering Detection, Noise Reduction, Push Video, P2P (Optional)
AI Features (Optional)	Crowd Detection, Queue Detection, Intrusion Detection, Loitering Detection, Line Crossing Detection, Enter/ Exit Counting, Parking Detection
Dimensions	Ø137 x H102 (mm)
Weight	890 (g)
Working Temp.	-20°C ~ 60°C / -4°F ~ 140°F
◊ Specification are subject to change without notice please contact us for any further inquiry of customization demands

Download

Document	Type	Date	Version	Size	Download
Manual		20250723		5.2 Mb
Datesheet		20220822		1.6 Mb
IP Scanner		20180726		1.7 Mb

Dimensions

Accessories

HLV-1WKQ Accessories
Pole Mount Adapter	L-shap Bracket	Ø3.5mm Stereo Jack Microphone
