HLV-1ZKC 1

HLV-1ZKC



  • 12 Megapixel Progressive Scan CMOS
  • H.264+ / H.264 / M-JPEG Compression
  • Provides 360 Degrees Panorama View
  • Region of Interest Function
  • Digital Noise Reduction
  • Hardware De-warp display mode
  • Wide Dynamic Range 80dB
  • Day & Night Manual Switch Time Control
  • Build-in IR 30M
  • Power over Ethernet
  • IR Cut Filter Mechanism
  • Micro SD Card Backup
  • 2-way Audio
  • IP66
  • IK10
  • Support iPhone / iPad / Android
  • SDK for Software Integration
  • Free Bundle 36 Ch Recording Software
Product Name H.264+ 12MP Fisheye Vandal Dome IP Camera
Model HLV-1ZKC
Max. Resolution 4048x3040 (12MP)
Sensor 1/2.3" Sony Starvis CMOS Sensor
Lens 1.8mm @ F2.0
Sensitivity Color: 0.05Lux (AGC ON),  B/W: 0.01Lux (AGC ON)
FOV 360° Fisheye and Panoramic Views
IR Distance 4 x High Power LEDs,  IR Distance 30 (M)
Video Format H.264+ / H.264 / MJPEG
Video Resolution Fisheye Overview:  3040x3040@30fps,   2048x2048@30fps,  1024x1024@30fps, 480x480@30fps
De-warp:  4048x3040@25fps,   3520x2640@25fps,  2880x2160@25fps, 2048x1536@25fps,   1600x1200@25fps,  1024x768@25fps, 640x480@25fps
De-Warping Mode 1O: Fisheye Overview
1P: Panorama
2P: Double Panorama
1R: 1 PTZ
4R: 4 PTZ
1P1R: Panorama + 1 PTZ
1P2R: Panorama + 2 PTZ
1P3R: Panorama + 3 PTZ
1O3R: Overview + 3 PTZ
Max. Streams 4 Streams
Audio Format G.711 (64K) / G.726 (32K, 24K)
Audio Input: Ø3.5mm Stereo Jack,
Output: Ø3.5mm Stereo Jack, Support 2 way Audio
Interface DIx1,  DOx1,  Micro SD Card Slot (Optional),  RJ45,  DC Jack
Network Protocol IPv6,  IPv4,  HTTP,  HTTPS,  SNMP,  SSL,  TLS,  DNS,  ICMP,  IGMP,  ARP,  SNTP,  QoS/DSCP,  IEEE 802.1X,  RTSP/RTP/RTCP,  TCP/IP,  UDP,  SMTP,  FTP,  PPPoE,  DHCP,  DDNS,  NTP,  UPnP,  Samba,  Bonjour,  ONVIF Profile S,  ONVIF Profile T,  ONVIF Profile G
Power Consumption DC 12V Max.: 8.3W,   PoE Max.: 7.1W
Special Features Region of Interest,  Smart Stream,  Advanced Smart Stream,  Motion Detection,  Privacy Mask,  Anti Fog,  Tampering Detection, Corridor Mode,  Push Video,  P2P (Optional)
Dimensions Ø137 x H58 (mm)
Weight 650 (g)
Working Temp. -20°C ~ 60°C   /  -4°F ~ 140°F
◊ Specification are subject to change without notice please contact us for any further inquiry of customization demands
Document Type Date Version Size Download
Manual       Mb
Datesheet   20230620   1.5Mb
IP Scanner   20180726   1.7Mb
HLV-1ZKC Accessories
Pole Mount Adapter L-shap Bracket Ø3.5mm Stereo Jack Microphone
